KIM-1 I/O Board

$49.00

This KIM-1 I/O board connects to the Application connector of the KIM-1 and provides various I/O options.

Out of stock

Email when stock available

SKU: KIM-IO Category:

Description

This KIM-1 I/O board connects to the Application connector of the KIM-1 and provides various I/O options.

Features

  • Barrel connectors of both 5 and 12 volts, with LED indicators (5.5mm OD x 2.1 mm ID with center positive)
  • TTY over RS-232 communication via a DB-9 connector
  • Cassette audio out (jumper configurable HI or LOW) a mono 3.5mm jack
  • Cassette audio in via a mono 3.5mm jack
  • TTY <-> Keyboard switch
  • Commodore floppy disk drive, or an SD2IEC, access via KIM-1 assembly routines
  • 2×13 header exposes all PA and PB signals, as well as passing 12v and GND.
  • 2×5 header allows for connection to RetroSpy’s or Corsham Technologies’ RAM/ROM boards.
  • Allows for the use of Corsham Technologies’ or RetroSpy’s SD Card System.

Includes full color manual and a single dupont jumper cable (color may vary).

Inspiration taken from a design by Bob Applegate of Corsham Technologies, LLC.
